3-way Junction Box
SLAM686-Y

  • 24A 450VAC
  • 2-6 holders, with terminal (screw type) and connector (plug wire type)
  • T100 working temperature
  • IP68 waterproof
  • PC, 94V-2 fire retardant
  • 4-8mm / 8-12mm / 10-14mm cable diameter

Can be used with the following products

  • Mini-LIGHTZ – SL201 (friction fit), SL211 (spring mount)
  • Marker-LIGHTZ – SL231 (friction fit), SL241 (spring mount)
  • 4W Spot-LIGHTZ – SL204 (surface mount), SL214 (spike mount)
  • 5W Spot-LIGHTZ – SL224 (Surface mount), SL234 (spike mount)

Define Your Product

Select the options below to define your product
Please select one option from each line.
Options will remain to enable product selection.
All lines must be selected to show a product.

Light Level and Beam Generator


Selected product: 3-way Junction Box
SLAM686-Y

Product Code: SLAM686-Y
